General
|
| DIMENSION |
3” x 2.97” x 2.28” (75.8 x 75.5 x 57.87 mm) |
| WEIGHT |
2.6 oz (75 g) |
| BATTERY LIFE |
10 hours |
| WATER RATING |
IPX7 |
Sensors
|
| HAS BUILT-IN RECEIVER |
|
| RECEIVER |
260/455 kHz |
Sonar features & specifications
|
| DISPLAYS SONAR |
|
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) |
|
| FREQUENCY |
260/455 kHz |
| BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) |
|
| WATER TEMPERATURE LOG |
|
Connections
|
| BLUETOOTH® CALLING |
|
Electrical Features
|
| TRANSMIT POWER |
7.78 dBm maximum |
Fishfinder features
|
| FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) |
|
| AUTOGAIN TECHNOLOGY (MINIMISES CLUTTER, MAXIMISES TARGETS) |
|
| ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) |
|
| A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) |
|
| WATER TEMPERATURE SENSOR INCLUDED |
|
| DEPTH RANGE SHADING |
|
Castable Fishfinder Features
|
| INCLUDED TEATHER LENGTH |
16.4 ft (5 m) |
| STREAMING RANGE |
61 m (200′) |
General
|
| Physical dimensions |
75.8 x 75.5 x 57.87 mm |
| Weight |
75 g |
| Water rating |
IPX7 |
| Operating temperature |
From -20° to 60° C |
| Charging temperature |
From 5° to 40° C |
Sonar Features & Specifications
|
| Frequencies supported |
260/455 kHz |
| Maximum depth |
From less than 0.6 m to 45 m |
Fishfinder Features
|
| Fish symbol ID (helps you identify fish targets) |
Yes |
| Autogain (minimizes clutter, maximizes targets) |
Yes |
| A-Scope (real-time display of fish passing through transducer beam) |
Yes |
| Scroll speed adjustment |
Yes |
| Water temperature sensor included |
Yes |
| Ice fishing flasher |
Yes |
Additional
|
| Included tether length |
5 m |
| Streaming range |
60 m |
| Download from Quickdraw contours community |
Yes |
| Depth range shading |
Yes |
| Mark waypoints on map |
Yes |
| Battery life |
10+ hours1 on internal USB-rechargeable battery |
1Battery life may vary depending on usage
